SFP 1.25G Single mode Single Fiber LC DDM Tx1550nm / Rx1310nm 10Km 20Km 40Km Optical Transceiver BIDI SFP Module

       Wirenet’s SFP-GE-BX-D SFP transceiver is compatible with the Small Form Factor Pluggable Multi-Sourcing Agreement (MSA). The transceiver consists of five sections: the LD driver, the limiting amplifier, the digital diagnostic monitor, the 1310nm FP laser(the 1550nm FP laser), and the PIN/TIA. The module data link up to 10km in 9/125um Single-mode fiber.

       This sfp 1.25 transceiver meets the Small Form Pluggable (SFP) industry-standard package utilizing an integral LC-Bi-directional optical interface connector. An enhanced Digital Diagnostic Monitoring Interface compliant with SFF-8472 has been incorporated into the transceiver. It allows real-time access to the transceiver operating parameters such as transceiver temperature, laser bias current, transmitted optical power, received optical power, and transceiver supply voltage by reading a built-in memory with an I²C interface.

       The optical output can be disabled by an LVTTL logic high-level input of Tx Disable, and the system also can disable the module via I²C. Tx Fault is provided to indicate the degradation of the laser. Loss of signal (LOS) output is provided to indicate the loss of an input optical signal of the receiver or the link status with the partner. The system can also get the LOS (or Link)/Disable/Fault information via I²C register access.

General Specifications

Absolute Maximum Ratings
