Model Number: WT-SFP-FE-BX-U
Fiber type: Single Fiber Single Mode
Transmission rate: 155Mbps
Working wavelength: Tx1310nm / Rx1550 nm
Transmission distance: 40KM
Fiber interface: Single LC interface
Wirenet Small Form Factor Pluggable (SFP) Optical Transceivers comply with the Small Form Factor Pluggable Multi-Sourcing Agreement (MSA) and are certified for use in Wirenet SFP products.
These 155M SFP Transceivers are available in 2km, 20km, 40km, 60km, & 100km transmission ranges for a variety of applications.
Features:
* Hot-pluggable
* Uncooled laser transmitter
* Hardened to operate in -40°F to +185°F (-40°C to +85°C)
* Single and dual fiber options available
* 21CFR(J) Class 1 laser safety standards
* RoHS compliant SFP MSA(INF-8074i)
* SFF MSA (INF-8074i)
* IEEE802.3ah 100Base-LX10
* 155Mbps ITU-T G.957 STM-1
* 155Mbps SONET OC-3
Specifications
Operating Supply Voltage: | 3.3V Typical (3.1V~3.5V) |
Operating Temperature: | -40°F to +185°F (-40°C to +85°C) |
Power Supply Current: | 150mA Typical (300mA max) |
Data Rates: | 155Mbps |
