GCYFTY HDPE Jacket Mini Air Blowing Cable Micro Fiber Optic Cable

GCYFTY HDPE Jacket Mini Air Blowing Cable Micro Fiber Optic Cable

Model Number: GCYFTY Air Blown Fiber Cable

Installation Temperature range: -30--+60℃

Operation and transport temperature: -10--+40℃

Sheath material: PE,LSZH

Length of cable: generally is 0.5km


share:

Description Contact Us

1.Cable Description

     The ABF is the product that with small diameter, lightweight, highly flexibility and proper stiffness, and it can be blown into the microduct of 5.0/3.5mm. The fibres are coated with a soft acrylate resin which provides excellent dimensional and thermal stability to cushion the fibres, in addition, the resin can be easily stripped in connecting the fibres. The outer sheath is a thermoplastic that is of low friction. The surface of the sheath is designed with special grooves, compared to the surface of the traditional optical fibre cable, it provides not only the high level of mechanical protection, but also the perfect blowing performance.

GCYFTY HDPE Jacket Mini Air Blowing Cable Micro Fiber Optic Cable

GCYFTY HDPE Jacket Mini Air Blowing Cable Micro Fiber Optic Cable

GCYFTY HDPE Jacket Mini Air Blowing Cable Micro Fiber Optic Cable

2. Features:

*  2、4、6、8 and 12 fibres options.

*  Stable structure, good mechanical and temperature performance.

*  Designed with special grooves to advance blowing distance.

*  Lightweight and proper stiffness , repeat installation.

*  Designed with no gel, easy stripping and handling.

*  Better costs advantage compared to traditional product.

*  Complete accessories, less manpower, lower installation time.


3. Application:

1. This micro cable for blowing into micro ducts.

2. Suitable for wiring in multiple minefields and places with severe electromagnetic interference.

3. Suitable for overhead and laying.

4. Long distance communication,  inter-office communication.


GCYFTY HDPE Jacket Mini Air Blowing Cable Micro Fiber Optic Cable


Characteristics:

1. Special composite material loose tube,  reducing the shrinkage of the tube in low temperature

2. Accurately control the excess length of optical fiber to ensure the stability of the performance of the optical fiber cable;

3. Unique process control to prevent sheath wrinkling during airblowing;

4. High-density polyethylene outer sheath to increase the air blowingdistance


TypeGCYFXY-**F(MTE +diameter)

MTE1.8MTE2.0MTE2.3MTE2.5MTE2.8
Fiber Type2~42~46~122~1214~24
Hdpe Jacket Thicknessstandard:0.20mm,min:0.15mm
Standard Diameter1.8mm2.0mm2.3mm2.5mm2.8mm
a.p. Weight2.6 kg/km4.0 kg/km5.0 kg/km6.0 kg/km7.0kg/km
Fiber Attenuation (Singlemode)1310nm/1550nm≤0.35/0.22dB/km
Max Tensile40N40N50N60N60N
Max Crunch600N/100mm
Allowable Min Static / Dynamic Radious Diameter10times/20 times cable diameter
Adapt Temstorage-30~+60℃; operation -10~+40℃; work -20~+50℃
Cable Life Time(Appoximate)25 years
