ABS Mini type DIN rail 2 core fiber optic terminal box Company

This WT-MINIDIN-02F/04F Fiber optic mini DIN rail mounted terminal box is available for the distribution and terminal connection for various kinds of optical fiber system, especially suitable for mini-network terminal distribution, in which the optical cables, patch cores or pigtails are connected，Can also be used alone with wall mounting。

Features

* Standard size, light weight and reasonable structure
* Material: ABS,
* Din guide rail, easy to install on rack panel in cabinet.
* Applicable to LC SC optical interface
* Compact design, beautiful appearance

Application
* Data centers, premise installations, telecommunication networks
* Ethernet, Fiber Channel, ATM, LAN, MAN and WAN
* Data communication and telecommunication networks
* Indoor/outdoor applications
Cable Management:

ABS Mini type DIN rail 2 core fiber optic terminal box

Dimensions (WHD)	901859.7mm
Material	ABS
Adapter Capacity	2pcs with SC Simplex or LC duplex adaptor
Numberof Cable Entrance/Exit	1/2
Capacity	2cores
Installation	DIN rolling guide, Wall-mounting
Drop Cable (Round)	Φ5.5mm
Optional Accessories	Adapters, Pigtails, Protection sleeve
Weight	31g（empty）
Color	Gray
Protection grade	IP55

Operation Conditions
Temperature	-40℃ -- 85℃
Humidity	≤85% at 30℃
Air Pressure	70kPa – 106kPa

Shipping Information
Package Contents	· miniDIN box, 1 unit; Nylon cable ties 2pcs ,Fusion fiber protection tube2pcs · Wall mount installation accessories, 2set
Package Dimensions(WHD)	1106520cm
Material	Bubble bag
Weight	50g
