Model Number: GYTA
PBT diameter: 2.2mm
Diameter: 10.5mm and customized
jacket material: PE LSZH HDPE
Temperature range: -20°~60°C
What is GYTA Fiber Optic Cable?
GYTA is an outdoor fiber optic cable commonly used in telecommunications networks, especially for long-distance, high-speed data transmission. It features a stranded loose tube design, making it durable and versatile in challenging environments.
Key Features of GYTA Fiber Optic Cable:
1. Structure:
GYTA cables contain optical fibers housed in loose tubes filled with water-blocking gel to protect against moisture.
The fibers,250μmm,are position in a loose tube made of a high modulus plastic.The tube are filled with a water resistant filling compound.A steel wire,sometimes sheathed with ployethylene(PE) for cable with high fiber count,locates in the center of core as a metallic strength member.
Tubes (and fillers) are stranded around the strength member into a compact and circular cable core.An Aluminum Polyethylene Laminate(APL) is applied around the cable core,which is filled with filling compound to protect it from water ingress,the cable is completed with a PE sheath.
2. Aluminum Tape Armor:
A key characteristic of GYTA cables is the longitudinal aluminum tape armor, which offers strong protection against rodent damage, mechanical stress, and environmental hazards.
3. Application:
* Ideal for outdoor installations, such as aerial (pole-mounted) or duct applications, due to its rugged design.
* The aluminum tape armor enhances durability, making it suitable for environments prone to physical damage.
* Long distance and local area network communication.
4. Advantages:
* Water Resistance: The water-blocking gel and aluminum armor protect the cable from moisture, making it suitable for wet conditions.
* Mechanical Durability: The armor and robust construction allow the cable to withstand harsh outdoor environments, including tension and external impacts.
* High Capacity: GYTA cables can support multiple fibers, enabling long-distance data transmission with minimal signal loss.
5. Characteristics:
* Steel wire strength filler protect tube fiber.Aluminum tape armord.
* Good ultra violet radiation resistant property.
* Good moisture-resistance
GYTA fiber optic cables are specifically designed for outdoor environments that require high-performance data transmission and protection against moisture and physical damage.
Technical Parameters
| CableCount | Outsheath Diameter | Weight | Minimumallowable TensileStrength（N） | MinimumallowableCrush Load(N/100nm) | MinimumBendingRadius(MM) | |||
| (MM) | (kg) | Short term | Long term | Short term | Long term | Short term | Long term | |
| 24-32 | 8.6 | 105 | 1500 | 600 | 1000 | 300 | 20D | 10D |
| 33-60 | 9.6 | 208 | 1500 | 600 | 1000 | 300 | 20D | 10D |
| 144 | 15.5 | 295 | 1500 | 600 | 1000 | 300 | 20D | 10D |
Packing Information
| Model No. | OD(mm) | Km/Reel | N.W./Reel(kg) | Reel Size(kg) | Weight for Package by Drum (kg) | Weight for Package by Polywood (kg) |
| GYTA | 10.0 | 1 | 95 | 55*75 | 126 | 123 |
| 2 | 190 | 55*100 | 250 | 235 | ||
| 3 | 285 | 55*110 | 348 | 335 | ||
| 4 | 380 | 68*110 | 445 | 440 | ||
| 5 | 475 | 68*120 | 555 | 540 |
Remark:
Package by Drum needs to be fumigated or provide fumigation certificate when exporting
While, package by Polywood can be exported directly.
