Model Number: WTLZP-05
Product size: 860*830*730 mm
Net weight:31KG
The diameter: 3.0-10.0mm
Capacity: 1800,1000,600,450,320,250,200,160M
share:
Portable field deployable tactical fiber optic cable reel has been optimized for using in harsh environments where mobility and rapid deployment of the cable are very essential. This assembly is specifically designed for field deployable applications. Particularly, it can broadcast the communication for film crews to connect HDTV camera equipment with central broadcasting trucks about events like music concerts and sporting events. This deployable assembly includes a marcaddy drum, breakout modules with ruggedised tails at each end, choice of connectors, tactical cable and a high durability protective conduit IP rated pulling sock.
Product size | 860*830*730mm |
Net weight | 31KG |
Packing size(Reel packing) | 585*570*470mm(The wooden case) |
Gross weight | 19KG |
Packing size(Roller rack) | 1070*780*220(The wooden case) |
Gross weight | 30KG |
The diameter | 3.0-10.0mm |
Capacity | 1800,1000,600,450,320,250,200,160M |
Note | Two wheel push and pull, car, folding, automatic line arrangement, with brake, pull rod can be telescopic |
