Full Duplex Communication Handheld Optical Fiber Talk Set tester for FTTH Network Cable Test

Full Duplex Communication Handheld Optical Fiber Talk Set tester for FTTH Network Cable Test

Model Number: AOT

Wavelength: A: 1310nm, B: 1550nm

Operation Style: Full Duplex Communication

Output Power: >-5dBm

Dynamic Range: SM fiber: >120km

Connector Type: FC/PC

Power Supply: 2 * AA batteries or AC/DC adapter

Dimensions: 170mm * 97mm * 38mm

Weight: About 380g

Inquire Now Next Product

Description Contact Us

Full Duplex Communication Handheld Optical Fiber Talk Set tester for FTTH Network Cable Test

Features
Talk by connecting with fiber
Full-duplex communication with high quality conversation and very low background noise
Light source capabilities
Wide dynamicrange: 45dB;Large dynamicdistance: >120km
Long/short mode for different distance
Power autonomyof 70 hours

Model
Wavelength	A: 1310nm, B: 1550nm
Operating Style	Full duplex communication
Output Power	>-5dBm
Fiber Type	SM
Dynamic Range*	SM fiber: 45dB
Dynamic Distance*	SM fiber: > 120 km
Connecting Adapter	FC / PC
Battery Charge	Optional
Operate Time	Above 12 hours
Power Supply	2 * AA batteries or AC/DC adapter
Size(HWD)	170mm * 97mm * 38mm
Weight	About 380g
Storage Temperature	-20 -- +60 ℃, < 90%RH
Operating Temperature	-10 -- +50 ℃, < 90%RH
