FTTH G652D Hybrid Cable 6 Core 2 Copper Electric Fiber Cable Armour Tubing Cable without Sheath

FTTH G652D Hybrid Cable 6 Core 2 Copper Electric Fiber Cable Armour Tubing Cable without Sheath

Special low-bend-sensitivity fiber provides high bandwidth and excellent communication transmission property.

share:

Description Contact Us

Features

1. Special low-bend-sensitivity fiber provides high bandwidth and excellent communication transmission property.

2. Two parallel FRP strength members ensure good performance of crush resistance to protect the fiber.

3. Simple structure, light weight and high practicability.

4. Novel flute design, easily strip and splice, simplify the installation and maintenance.

5. Low smoke, zero halogen and flame retardant sheath.


Cable CountOut sheath DiameterWeightMinimum allowable
Tensile Strength (N)
Minimum allowable
Crush Load(N/100mm)
Minimum Bending
Radius(MM)
Storage temperature
(MM)(KG)Short termLong termShort termLong termShort termLong term°C
21.6*3.34.460120200100020D10D-20 to +60
21.8*3.76.060120200100020D10D
22.0*4.17.290150200100020D10D
22.4*4.910.090150200100020D10D
22.8*5.713.5160300200100020D10D
23.0*6.114.5160300200100020D10D



Application

1. Adopted to indoor distribution.
2. As pigtail of communication equipment.
3. Suitable for communication equipment servrd.
4. Can be installed conveniently and perated simply.
