144-fiber Dry Structure Indoor Fiber Optic Cable, with 3.0mm subunit,Indoor Fiber Optic Cable
Application:
1. Used in indoor cabling. especially used as distribution cable;
2. Used as interconnect lines of equipments. and used in optical connections in optical communication equipment rooms and distribution frames;
3. Used in pigtails and patch cords.
Characteristics:
1. Good mechanical and environmental characteristics;
2. Flame retardant characteristics meet the requirements of relevant standards;
3. The mechanical characteristics meet the requirements of relevant standards;
4. Soft. flexible. easy to splice. and with big capacity data transmission;
5. Meet various requirements of market and clients.
Fiber Parameters
| No. | Items | unit | Performance Specification | |
| OM4 | ||||
| 1 | Core diameter | μm | 50±2.5 | |
| 2 | Cladding Diameter | μm | 125±1.0 | |
| 3 | Core non-circularity | % | ≤6.0 | |
| 4 | Cladding non-circularity | % | ≤2.0 | |
| 5 | Core-cladding concentricity | μm | ≤1.0 | |
| 6 | Coating Diameter | μm | 245±10 | |
| 7 | Cladding -coating concentricity | μm | ≤12.5 | |
| 8 | Effective Band width(min.) | 850nm | MHz.km | ≥4700 |
| 1300nm | MHz.km | ≥500 | ||
| 9 | Attenuation(max.) | 850nm | dB/km | 3.5 |
| 1300nm | 1.5 | |||
Cable Parameters
| Items | Specifications | |
| Fiber Count | 144 | |
| Colored Coating Fiber | Dimension | 250±15μm |
| Color | Blue、Orange、Green、Brown、Gray、White、Red、Black、Yellow、Purple、Pink、Aqua | |
| Cable Subunit | Dimension | 2.9±0.1mm |
| Material | PVC | |
| Color | Aqua | |
| Strength Member | Kevlar | |
| Printing Marks | 〈1〉～〈12〉 | |
| Central Strength Member | FRP | |
| Outer Jacket | Dimension | 17.5±0.5mm |
| Material | PVC | |
| Color | Aqua | |
Mechanical and Environmental Characteristics
| Items | Unite | Specifications |
| Tension（Long Term） | N | 500 |
| Tension（Short Term） | N | 1200 |
| Crush（Long Term） | N/10cm | 300 |
| Crush（Short Term） | N/10cm | 1000 |
| Min. Bend Radius（Dynamic） | mm | 20D |
| Min. Bend Radius（Static） | mm | 10D |
| Installation Temperature | ℃ | -10～+60 |
| Operating Temperature | ℃ | -20～+60 |
| Storage Temperature | ℃ | -20～+60 |
Ordering Choice
● Fiber type: SM 9/125. MM 50/125. 62.5/125 or OM3/OM4
● Fiber Count: 1~144C
● Sheath Material: PVC. LSZH
● Sheath Color: Yellow. Orange. Aqua or Customized
