China SM MM OM3 OM4 FTTH Fiber optic LC APC Fast Connector Metal V-groove

SM MM OM3 OM4 FTTH Fiber optic LC APC Fast Connector Metal V-groove

Introduction

1.the fast connector is designed for high quality and high efficiency
   for installation.
2.the structure of crimping position is a unique design, and need not
   gluing, polishing neither any consumables.
3.could be reused, and convenient for field installation.
4.adopted fiber pre-installed structure.

Features

Low insertion loss and back reflection loss;
Ferrule end surface predomed;
Boots in a variety of colors;
100% interferometer measurement;
Various fiber cable option; G652D, G657A, G657B3, OM1, OM2, OM3, OM4 option;

Application
Patch panels
Distribution frames
Maintenance or emergency restoration of fiber networks
FTTH Outlets
Connection at the desk for LAN environments
Distribution frames
Maintenance or emergency restoration of fiber networks
FTTH Outlets
Connection at the desk for LAN environments

Fast Connector Specification
Mode	SM		MM
Polish	UPC	APC	PC
Insertion Loss	Typical ≤0.2dB Maximum ≤0.3dB		≤0.25dB
Return Loss	≥50dB	≥65dB	≥35dB
Interchangeability	≤0.2dB
Repeatability	≤0.1dB
Durability	≤0.2dB (500 times mating)
Tensile Strengh	≥50N
Temperature	≤0.2dB (-40+85 sustain 100 hours)
Humidity	≤0.2dB (+25+65 93 R.H.100 hours)
