The MPO integrated tester integrates the basic functions of MPO testing, including functional modules such as light source, optical power meter, and end detector, and supports 24-core MPO polarity and loss testing (downward compatible with 12-core, etc.).
The instrument is equipped with a 5.6-inch color touch screen, and integrates the detection function of the MPO terminal detector to ensure the cleanliness of the connector.
The integrated and convenient MPO link solution can ensure a fast and reliable workflow when testing and verifying the network link connected by MPO, which greatly facilitates the data center computer room and on-site construction and maintenance work.
Application
* Simultaneous testing of polarity and loss of a single instrument
* Support 24-core, 12-core and other link tests * 5.6 inch LCD touch screen use * Customizable pass/fail thresholds * Any two instruments can be used remotely and in different places * Support USB interface end detector function (optional)
Type | MPO integrated tester |
OLS |
Wavelength | 1550nm(optional) |
Output power | ≥-5dBm |
Spectral width (FWHM) | ≤5nm |
Frequency | CW、270、1K、2KHZ |
Power stability | ≤±0.1 |
OPM |
Detector type | InGaAs |
Wavelength | 850nm、1300nm、1310nm、1550nm |
Measuring range | +3～-50 dBm |
Power measurement linearity | ±0.1 dB |
Power measurement uncertainty | ±0.25 dB |
Port | MPO Male connector |
Power unit | dBm、dB、xW |
Resolution ratio | 0.01dB |
Polarity detection | A、B、C & user-defined |
Record storage | Applied |
General power meter |
Wavelength test range | 800～1700nm |
Wavelength | 850/1300/1310/1490/1550/1625nm |
Measuring range | +26 ～ -50 dBm |
Uncertainty | ≤ 0.25 dB |
VFL |
Wavelength | 650nm |
Output power | 10mW |
Other |
Display size | 5.6-inch TFT color screen |
Power supply | 7.4V 4000mAh lithium battery/Micro USB |
Automatic shutdown time | user-defined optional |
Low battery warning | Icon flashing |
Communication interface | Micro USB |
Operating temperature（℃） | -10～+60 |
Storage temperature（℃） | -25～+70 |
Dimension(mm) | 260×155×73 |
Weight(g) | 1250 |
