Model Number: BML205
Application: fiber break locator
Adapter: 1.25mm&2.5mm
Max Capacity: 25mW
Single package size: 25X12X7 cm
Single gross weight: 0.5 kg
1. Feature
* test fiber fault
* 1mw~25mw optional
* 1mw for 5m
* 1.25mm 2.5mm adapter
2. Specification
| BML205-1 | BML205-10 | BML205-15 | BML205-20 | BML205-25 | |||
| Wavelength | 650nm±20nm | ||||||
| Output Power | >1mW | >10mW | >15mW | >20mW | >25mW | ||
| Dynamic Distance | >5 km | >10km | >13km | >15km | >17km | ||
| Connector | 2.5mmor1.25mmUniversalconnector | ||||||
| Storage Temperature | -20--+60°C,<90%RH | ||||||
| Operating Temperature | -10--+50°C,<90%RH | ||||||
| Power Supply | AA*2 | ||||||
| Weight | 0.4kg | ||||||
3. Attention
* Tested by FOD 1205 H650nm optical power meter
* The distance is tested by G.655,singlemode,lab level fiber
* Standard connector is 2.5mm UPP,1.25mm UPP will be customised and increase the cost
