Model Number: Huawei mini sc adapter
Insertion Loss: ≤ 0.2dB
Insert-pull test: 1000 times
Connector Type: MIni SC APC
This optical fiber adapter is compatible with Huawe MINI SC connectors, easy and fast to operate. It is environmentally sealed and mechanically protected for 1-fiber simplex SC interface connections. The inner cover protects the ferrule end face from scratches when mating with the socket; one-hand bayonet mechanical latch.
It provides a quick installation solution and has good performance in mating sockets/adapters. The industrial panel mount plastic adapter acts as a sealed feed-through for fiber connections. The new industrial integrated flange mount adapter is designed for tight side-by-side applications.
Features:
* Provides low-profile straight-in sockets
* No special tools are required for installation, faster network deployment and customer installation
* 100% tested before delivery, built in a controlled environment
* Provides excellent weather resistance for FTTA and other outdoor applications
* Allows flexibility to use with NAP boxes, CTO boxes, enclosure boxes
* Reduce deployment costs by utilizing plug-and-play solutions.
Product name | Waterproof fiber optic adapter |
Insertion loss | ≤0.2dB |
Insert-pull test | 1000 times |
repeatability | ≤0.1 dB |
Tensile strength | ≥10 kg |
Operating temperature | -40°C~85°C |
